Cod: 011590

Magico Abete Bianco H10 SCIVOLO TUNNEL

Magico Abete Bianco is a big tree where children enter, ascend, observe and descend through a very long tubular slide.

Size: 354 x 520 H 950 cm

HC: 150 cm

Area: 695 x 1000 cm

Age: 5-12

Thanks to a production that uses only energy from renewable sources and use of controlled harvest timber (PEFC -FSC certified forests) and obtained at km. Zero, Legnolandia manages to concretely cut down harmful CO2 emissions. Wood is a renewable and easily recyclable raw material with a low energy toll. The colored parts are made of 100% recycled and recyclable polyethylene. This product meets the requirements of CAM (Minimum Environmental Criteria) under GPP (Green Public Procurement) the environmental policy tool provided for all public administrations.

Find out more

Description

The Magical Silver Fir is the evolution of the series called Trees by Legnolandia which includes 25 articles of different sizes and suitable for different ages. This play equipment is ideal to characterize large areas as shopping centers, urban parks, beaches, squares in any public or private space. The gaming activities are simple and risk-free, the main aspect of the play is based on the rewarding achievement of a considerable height from the ground for children over 3 years old safely. The access devices to the large panoramic tower with slide are designed to enhance the achievement of the goal and to prevent the access to younger children (<3 years old). The internal climb takes place through the use of adventurous wood steps ladders, which allow the ascent to only one user at a time and to allow an easy and safe access. Even adults can enter the structure, for maintenance or to control the phases of the game.

Structure

Composed of PEFC – FSC certified and statically calculated laminated gluelam wood according to the current Law in force. The pyramid-shaped isostatic structure offers an excellent wind resistance and to the working load, thus minimizing the use of beton during the installation. This contributes to reduce the costs, and it facilitates the de-building operations at the end of the life cycle.

The structure does not need foundations, it is simply placed on the ground on existing stalls or on three concrete blocks and it is anchored by fixing the steel brackets included in the supply.

Duration

All wooden parts are autoclave treated by pressure injection of mineral salts according to EN-351 standards to withstand the actions of time and weather for a long time. As with all park games, it should be subjected to annual inspection cycles as per current standards. Legnolandia offers a 10-year warranty against rotting.

Versions

TheMagical Silver Fir is available in two versions:

Magical Silver Fir 10 mt height
Magical Silver Fir 16 mt height

Both models can be equipped with one or more tubular slides made of polyethylene or stainless steel. The shape of the slides can be customized (straight – curved or spiral) to adapt the play equipment to the available space. Access to the tower is through a metal ladder or through a climbing wall with holds.

Internally the structure is equipped with a wooden ladder that goes up to the floor of the slide to allow children to “observe the world from above”. This tree-shaped playground tower is equipped with different portholes in transparent anti-breakage polycarbonate.

Safety

All the devices are complying with the European safety standards on equipment installed in the play areas UNI EN-1176: 2017. The structure can be easily dismantled and it is easily repositioned or disposed at the end of the life cycle according to the principles of GPP. The safety flooring must be suitable for a fall height (HIC) of 150 cm according to the UNI EN-1176 and UNI EN-1177 standards.

Legnolandia suggests the use of natural substrates in respect of the environment and to reduce the costs such as fine sand or gravel to 2-8 mm. This, like all Legnolandia playgrounds, is also covered by R.C. insurance that relieves the owner or manager of the area from any liability arising from product defects.
